Power Output - Both channels driven
(0.05% THD, RMS, 20 Hz - 20 kHz)
160 watts x 2 @ 8 Ω
240 watts x 2 @ 4 Ω

Power Output - Both channels driven
(0.9% THD, RMS, 20 Hz - 20 kHz)
180 watts x 2 @ 8 Ω
270 watts x 2 @ 4 Ω

Current Capacity
45 amps peak per channel

Frequency Response
10 Hz - 100 kHz, +0/-3 dB

Total Harmonic Distortion (THD)
< 0.01 %, average listening levels
< 0.05 %, 160 watts x 2 @ 8 Ω

Interchannel Crosstalk
> 50 dB at 20 kHz
> 70 dB at 1 kHz

Signal to Noise Ratio - IHF A-weighted
Line in: - 103 dB (input shorted)
Digital in: - 106 dB

Amplifier Damping Factor
> 800 at 20 Hz

Preamp Stage Input Sensitivity
300 mV in for 1 V at Pre Out jacks
Total Preamp Stage Gain: 10 dB
Max Output Unbalanced: 7 V
Max Output Balanced: 9 V

Power Amplifier Stage Sensitivity
1 V at Bypass/Amp In for 28 V at Speaker Out
Total Amp Stage Gain: 28 dB

Supported DAC Sampling Rates
USB: up to 384 kHz / 32-bit PCM
DSD Native: DSD 64, DSD 128, DSD 256
DSD over PCM (DoP) at 384 kHz
Coax/Opt: up to 192 kHz / 24-bit PCM

Digital to Analog Converter
ESS Sabre32 Reference ES9018K2M
384 kHz / 32-bit

USB 2.0 Controller
VIA VT1731, 384 kHz / 32-bit

Headphone Amplifier
Texas Instruments TPA6120A
Output Impedance 10 ohms

XLR Pin Identification
1 = Ground (Shield)
2 = Positive
3 = Negative (Return)

Input Impedance
Unbalanced: 24 k Ω
Balanced: 100 k Ω per leg

Output Impedance
Unbalanced: 100 Ω
Balanced: 470 Ω per leg

Dimensions
Width: 17-1/4" (437 mm)
Depth: 16-1/4" (413 mm)
Depth, with cables 17-1/4" (437 mm)
Height, with feet: 5-7/8" (150 mm)
Height, without feet: 5-1/4" (133 mm), 3U

Net Weight
33 lb. (15 kg)

Power Requirement
Standby: 0.5 watts
Idling power: 70 watts
Maximum: 750 watts
110-125 VAC 60 Hz or 220-250 VAC 50 Hz
AC mains voltage is set on rear
